Startech 1 Port Serial-to-IP Ethernet Device Server – DIN Rail Mountable


10 in stock

SKU: 303833080334 Categories: ,


Startech 1 Port Serial-to-IP Ethernet Device Server – DIN Rail Mountable
This 1-Port Serial Device Server lets you remotely access and manage an RS232 serial device over a local area network (LAN), for a simple and cost-effective serial-over-IP control solution. For more control options, the device server is compatible with the free, StarTech Serial Device Application Software NETRSAPP. When coupled with the NETRS232, this handy application for iOS, Android, and Chrome Browser lets you build a custom serial control interface that’s tailored to your specific application. Flexible power and mounting options For installation flexibility across a variety of environments, you can power the device server using the provided 12V DC power adapter, or using the integrated 10~30V DC terminal block. Plus, the device server is DIN rail mountable for out-of-the-way installations. Protects your investment To help ensure reliable performance and prevent possible damage, the serial device server offers 15KV ESD (Electrostatic Discharge) protection, so you can rest assured that the device server won’t become damaged due to externally generated ESD. Customizable and wide compatibility This highly-customizable device server is easy to configure to suit your application. For easy setup, Windows users can use the provided Virtual COM port software, or the versatile web-based interface. The RS232 device server supports Telnet (an operating system independent communication protocol), so it can be integrated into mixed OS environments (Windows, Mac, Linux). Plus, it supports VCOM, TCP Server/Client, UDP, HTTP, DHCP, ICMP(PING), Static IP, and ARP protocols. Download the application software and manage your serial devices with ease Download the StarTech serial control software from the Apple App Store, the Google Play™ Store, or the Chrome Web Store. The NETRS232 is backed by a StarTech 2-year warranty and free lifetime technical support. More from the Manufacturer:
Manufacturer StarTech
Manufacturer Part Number NETRS232
Brand Name StarTech
Product Name 1-Port Serial-to-IP Ethernet Device Server – RS232 – DIN Rail Mountable
Product Type Device Server
Media & Performance Media Type Supported Twisted Pair
Wireless Specifications Wireless LAN No
ISM Band No
UNII Band No
Network & Communication Ethernet Technology Fast Ethernet
Network Standard 10/100Base-TX
Interfaces/Ports Network (RJ-45) Yes
Phone Line (RJ-11) No
Network (RJ-11) No
Serial Port Yes
Parallel Port No
Centronics Port No
PoE (RJ-45) Port No
Number of Network (RJ-45) Ports 1
Number of Serial Ports 1
Power Description Input Voltage 12 V DC
Physical Characteristics Color Black
Form Factor Rail-mountable
Height 0.9″
Width 2.2″
Depth 3.7″
Weight (Approximate) 2.40 Oz
Miscellaneous Package Contents 1-Port Serial-to-IP Ethernet Device Server – RS232 – DIN Rail Mountable 1 x DIN Rail Kit 1 x Terminal Block 1 x Universal Power Adapter (NA/UK/EU) 1 x Software CD 1 x Instruction Manual
Compatibility Windows® 2000, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016 Linux Linux: The included software does not support Linux to emulate a local COM port Linux users would need to use Telnet
Certifications & Standards CEFCCIEEE Standards:802.3802.3u
Environmentally Friendly Yes
Environmental Certification RoHS, REACH, WEEE
TAA Compliant Yes
Warranty Limited Warranty 2 Year
